4K 60Hz (4:2:0) 2x2 Video Wall Controller, Seamless HDMI Matrix, Multiviewer

The JTECH-VWM04 is a 4-input, 4-output, seamless switching matrix, video wall controller and multiviewer device all rolled into one. While in matrix mode, seamlessly route any of your 4 available input signals to any combination of outputs without delay or picture loss. Want to view more than one signal on your single display at a time? No problem. Engage the multiviewer function on your output port and choose from 5 different multiviewer layouts, including 2x2, 1x3L, 1x3U, 1x4 & 4x1. Reinvent your interior space by taking advantage of the video wall function and have any source signal stretched across all 4 output displays. Arrange your output displays in up to 10 different video wall configurations, including 2x2, 1x4 and 4x1. 10 different video wall configurations means the user gets the exact style and creative expression they desire.

✅ 3 Different Operation Modes – Matrix | Video Wall Controller | Multiviewer

✅ Seamless Switching (< 40ms switching speed) | HDMI Video Output Port Mute function

✅ Output Scaling – 1080P / 720P / 2560 x 1440 / 1920 x 1200 / 1360 x 768/ 4K@30Hz

✅ HDMI Specification – HDMI 1.4, HDCP 2.2 | Supported Audio Format – PCM

✅ 10 Different Video Wall Configurations – 2x2, 1x4, 4x1 & more | 5 Different Multiviewer Presets – 2x2, 1x3L, 1x3U, 1x4, 4x1

✅8 Customizable routing and display mode presets | Adjustable custom audio delay (0 – 250 ms) per output

✅ Variable Video Placement – Offset video content on both “x” & “y” axes & rotate 180°; Individual HDMI Output Color Settings – Brightness | Contrast | Saturation | Hue | RGB; Custom Source Selection and Crop & Zoom function for complete picture-in-picture customization
